Yaskawa SGMJV-04AAA21 Servo Motor 400W

Series#: Yaskawa

Product Details

YASKAWA SGMJV-04AAA21 is a 400 W rotary servo motor from the Sigma-5 (Σ-V) SGMJV series.
It is a 200 V class motor with a rated torque of 1.27 N·m and an instantaneous peak torque of 4.46 N·m.
The SGMJV-04AAA21 uses a 13-bit incremental encoder.

Specification

The YASKAWA SGMJV-04AAA21 is a rotary servo motor in the Sigma-5 (Σ-V) SGMJV series. Key product facts: Model Number: SGMJV-04AAA21 Series: Yaskawa Sigma-5 (Σ-V) Motor Family: SGMJV rotary servo motor Rated Output: 400 W Voltage Class: 200 V Rated Torque: 1.27 N·m Instantaneous Peak Torque: 4.46 N·m Encoder Type: 13-bit incremental encoder Shaft: Straight shaft without key Option: Without additional option The model code identifies the 400 W version of the SGMJV family with the 200 V specification and 13-bit incremental encoder.
